2 x Socket SP3 (LGA 4094)
AMD EPYC™ 7003 Series
-
Total Slots :
32 (8-channel per CPU, 16 DIMM per CPU)
Memory Type :
DDR4 3200 RDIMM
DDR4 3200 LRDIMM
DDR4 3200 LR-DIMM 3DS
Memory Size :
256GB, 128GB, 64GB, 32GB, 16GB
* Refer to support page for more information
-
Rear:
- 8 x PCIe x16 slots (Gen4 x16 link, FH,FL) for dual-slot GPU cards
- 1 x PCIe x16 slots (Gen4 x16 or x8 link, FH,HL) or OCP3.0 NIC socket (optional)
- 1 x PCIe x8 slots (Gen4 x8 link, LP,HL) (optional)
Front:
1 x PCIe x16 slot (Gen4 x8 link, FH,HL) for HBA/RAID cards
-
Optional kits Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card
-
8 x 3.5" or 2.5" Hot-swap Storage Bays (Backplane Supports 8 x SATA/SAS/NVMe Devices)*
Modular support of 2 x M.2 sockets (Gen4 x4 link, up to 22110) by SKU configuration.
*SATA/SAS drive support required an additional HBA/RAID card.
-
1 x Q-code/port-80 LED
2 x USB 3.2 Gen1 ports
-
1 x Management port (RJ45)
-
Rear:
1 x Location LED
Front:
1 x Power Button/LED
1 x Location Button/LED
1 x Message LED
-
Please find the latest OS support from
https://servers.asus.com/support/os
-
ASUS Control Center Enterprise (in-band)
ASMB10-iKVM for (out-of-band/BMC AST2600)
-
BSMI, CE, FCC(Class A)
-
800mm x 440mm x 175.6mm (4U)
-
4U
-
Net Weight: 39 Kg.
Gross Weight: 49 Kg.
-
2+2 Redundant 2200W/3000W 80 PLUS Titanium Power Supply
-
Operation temperature: 10? ~ 35? / Non operation temperature: -40? ~ 70? Non operation humidity: 20% ~ 90% ( Non condensing)
