SUPERMICRO 1U server 1xXeon D-2123IT 4x DDR4 ECC RDIMM, SSD M.2 NVMe PCIe4 SPI Capable Vertical

Na objednávku
27 898 Kč bez DPH 23 056 Kč

Poptat zboží
Hlídat cenu
Přidat k porovnání
Přidat k oblíbeným
SUPERMICRO
2376833
SYS-E300-9D-4CN8TP
36 měsíců
  • Poradna a návody
  • Vhodné pro
Popis produktu
Product SKUs

SYS-E300-9D-4CN8TP
  • SuperServer E300-9D-4CN8TP (Black)
Motherboard


Super X11SDV-4C-TP8F
Processor/Cache

CPU
  • Intel® Xeon® processor D-2123IT,
    CPU TDP support 60W
Cores / Cache
  • 4 Cores, 8 Threads
System Memory

Memory Capacity
  • Up to 512GB DDR4 ECC LRDIMM
  • Up to 256GB DDR4 ECC DIMM
  • 4 DIMM slots
Memory Type
  • 2666/2400/2133MHz ECC LRDIMM and ECC DIMM
  • Operating speed up to 2400MHz
DIMM Sizes
  • RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB
  • LRDIMM: 16GB, 32GB, 64GB, 128GB
Memory Voltage
  • 1.2 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors
      (using ECC memory)
On-Board Devices

Chipset
  • System on Chip
SATA
  • SATA3 (6Gbps) ports via SoC controller
Network Controllers
  • Quad 1GbE with Intel I350-AM4
  • Dual 10GBase-T with Intel X557
  • Dual 10G SFP+ via SoC
IPMI
  • Support for Intelligent Platform
  • Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • Aspeed AST2500 BMC
Input / Output

SATA
  • SoC controller for 4 SATA3 (6Gbps) ports
LAN
  • 2x 10G SFP+ ports
  • 2x 10GBase-T LAN ports
  • 4x 1GbE LAN ports
  • 1 Dedicated IPMI LAN port
USB
  • 2 USB 3.0 ports (rear)
Display
  • 1 VGA port
TPM
  • 1 TPM 2.0 header

Chassis

Form Factor
  • Compact
Model
Dimensions

Width
  • 10.43" (264.8mm) / 15" (381mm) - pkg.
Height
  • 1.7" (43mm) / 10.87" (276mm) - pkg.
Depth
  • 8.9" (226mm) / 5.59" (142mm) - pkg.
Weight
  • Gross Weight: 7.5 lbs (3.4 kg)
  • Net Weight: 3.45 lbs (1.56 kg)
Available Colors
  • Black
Front Panel

Buttons
  • Power On/Off button
LEDs
  • Power LED (Hard drive activity LED)
Expansion Slots

PCI-Express
  • 1 PCI-E 3.0 x8 slot
Drive Bays

Internal
  • 1 Fixed 2.5" drive bay with bracket (when AOC area is not occupied)
System Cooling

Fans
  • 3x 40x28mm 4-PIN PWM Fan
Power Supply

DC Power Adapter with PFC
System BIOS

BIOS Type
  • 128Mb SPI Flash with AMI BIOS
BIOS Features
  • PCI 3.0
  • ACPI 5.0
  • USB Keyboard support
  • Hardware BIOS Virus protection
  • SMBIOS 2.8
  • UEFI 2.4
  • RTC (Real Time Clock) Wakeup
Management

Software
  • Intel® Node Manager
  • IPMI 2.0
  • KVM with dedicated LAN
  • NMI
  • SUM
  • SuperDoctor® 5
  • Watch Dog
Power Configurations
  • ACPI Power Management
  • +12V DC Power Input
  • Control of power-on for recovery from AC power loss
  • CPU thermal trip support for processor protection
  • M.2 NGFF connector, Node Manager Support, SDDC, System level control, UID, WOL
Fan
  • Fans with tachometer status monitoring
  • Status monitor for speed control
  • Low noise fan speed control
  • Pulse Width Modulated (PWM) fan connectors
Operating Environment / Compliance

RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       0°C to 40°C (32°F to 104°F)
  • Non-operating Temperature:
       -40°C to 70°C (-40°F to 158°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)
