| Standard Parts List |
| |
| |
Part Number |
Qty |
Description |
| Air Shroud |
MCP-310-49003-0N |
1 |
SC846 Intel DP X9, X8 PC air shroud 1368x13/12x13MB |
| HD Backplane |
BPN-SAS-846A |
1 |
24-port 4U SAS 6Gbps direct-attached backplane, support up to 24x 3.5-inch SAS2/SATA3 HDD/SSD |
| Cable(s) |
CBL-0071L |
1 |
ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF |
| Cable(s) |
CBL-0160L |
2 |
US POWER CORD 16AWG, PB FREE |
| Cable(s) |
CBL-0217L |
1 |
16PIN CNTL PANEL CONVERTER CBL FOR SC826,PBF |
| Part(s) |
MCP-120-00061-0N |
7 |
Blank FH L-bracket (5x5 square hole) |
| Part(s) |
MCP-230-82501-0N |
1 |
Top cover for SC213,216,825,826,835,836,936,846 |
| Part(s) |
MCP-290-00088-0N |
1 |
SC119 Intrusion assembly |
| Part(s) |
MCP-290-84603-0N |
1 |
SC846 HDD Backplane Bracket |
| Part(s) |
MCP-290-84608-0N |
1 |
Dual HDD opening dummy cover for 846B chassis |
| Fan(s) |
FAN-0125L4 |
2 |
80x32 mm 6.7K RPM SC836 Rear Exhaust Fan w/ Housing |
| Fan(s) |
FAN-0127L4 |
3 |
80x80x38 mm 7K RPM SC846 Middle Fan w/ Housing |
| Front Panel |
MCP-280-82601-0N |
1 |
Front control board adapter (TB826) for SC216,826,936,846 |
| Drive Tray(s) |
MCP-220-00075-0B |
24 |
Black gen 5.5 hot-swap 3.5" HDD tray |
| Power Distributor |
PDB-PT846-2824 |
1 |
PDB with 23pairs input connector support SC846B |
| Power Supply & Accessory |
PWS-920P-SQ |
2 |
920W 1U Redundant PWS W/ Quiet Mode |
| Power Supply & Accessory |
MCP-290-84604-0N |
1 |
SC846 PDB Cover |
| Mounting Rail(s) |
MCP-290-00057-0N |
1 set |
Rail set, quick/quick, default for 4U 17.2" W |
| Mounting Rail(s) |
MCP-410-00007-0N |
1 |
Rail screw bag |
| Rear Window |
MCP-240-84602-0N |
1 |
846B rear window which support 2 X 2.5" HDD module and DVD |
= Most optimized Chassis for SuperServer Configuration
