ASRock PC DeskMeet B660 LGA1700(65W), 4x DIMM DDR4, PCIe x16, 2x M.2 + M.2E, 3x SATA,1Gb LAN, HDMI, DP, VGA, 500W

Mini PC DeskMeet B660 podporuje procesory Intel 12. generace (LGA1700) a má sloty pro 4x DDR4 RAM až 128GB. Nabízí 3 SATA, 2x M.2 a grafiku přes HDMI, DP, D-Sub. Kompakt s objemem 8L obsahuje 500W napájení (80+ Bronze). Vhodný pro domácí i kancelářské použití.
Na objednávku
6 113 Kč bez DPH 5 052 Kč

Poptat zboží
Hlídat cenu
Přidat k porovnání
Přidat k oblíbeným
ASROCK
1452917
DESKMEET B660/B/BB/BOX
24 měsíců
  • Poradna a návody
  • Vhodné pro
Popis produktu
  • Supports 12th Gen Intel Core™ Processors (LGA1700)
  • Supports MAX Height ? 54mm CPU Cooler
  • Supports 4 x DDR4-3200MHz DIMMs, up to 128GB
  • 1 x PCIe 4.0 x16
  • Graphics Output Options:DisplayPort, HDMI & D-Sub
  • 3 x SATA3
  • 1 x Hyper M.2 (PCIe Gen4 x4 & SATA3)
    1 x Hyper M.2 (PCIe Gen4 x4)
  • 1 x USB 3.2 Gen1 Type-C Port
  • 4 x USB 3.2 Gen1 Type-A port (2 Front, 2 Rear)
  • 4 x USB 2.0 Type-A port (2 Front, 2 Rear)
  • 1 x M.2 Key-E for Wi-Fi
  • 500W power supply (80+ Bronze)
  • 8 Liter compact size
  • CPU
    - Supports 12th Gen Intel® Core™ Processors (LGA1700)
  • Cooler
    - Supports Intel® CPU Cooler (Max. Height ? 54mm)
  • Memory
    - Supports Dual Channel DDR4 Memory Technology
    - 4 x DDR4 DIMM slots (Max. 128GB)
    - Supports DDR4 3200/2933/2800/2666/2400/2133 non-ECC, un-buffered memory*

    *Supports DDR4 3200 natively.
  • Chipset
    - Intel® B660
  • Graphics
    - Supports a discrete Dual slot Graphics card up to 20CM
  • Audio
    - Realtek ALC897 Audio Codec
  • Storage
    - 3 x SATA3 6.0Gb/s ports
    - 1 x Hyper M.2 Socket (M2_1), supports type 2280 SATA3 6.0Gb/s & PCIe Gen4x4 (64 Gb/s) modes*
    - 1 x Hyper M.2 Socket (M2_2), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*

    *Supports Intel® Optane™ Technology
    Supports NVMe SSD as boot disks
    Supports Intel® Volume Management Device (VMD)
  • LAN
    - Giga PHY Intel® I219V
  • Expansion Slots
    - 1 x PCIe 4.0 x 16
    - 1 x M.2 Socket (Key E), supports type 2230 Wi-Fi/BT module and Intel® CNVi (Integrated Wi-Fi/BT)
  • Front I/O
    - 1 x Headphone/Headset Jack
    - 1 x USB 3.2 Gen1 Type-C
    - 2 x USB 3.2 Gen1 Type-A
    - 2 x USB 2.0 Type-A
  • Rear I/O
    - 1 x DisplayPort 1.4
    - 1 x HDMI
    - 1 x D-Sub
    - 2 x USB 2.0
    - 2 x USB 3.2 Gen1 Type-A
    - 1 x RJ-45 LAN Port
    - HD Audio Jacks: Line in / Front Speaker / Microphone
  • Connectors
    - 1 x Chassis Intrusion Header
    - 1 x CPU Fan Connector (4-pin)
    - 1 x Chassis/Water Pump Fan Connectors (4-pin)
    - 1 x 24 pin ATX Power Connector
    - 1 x 8 pin 12V Power Connector
    - 1 x Front Panel Header
    - 1 x USB 2.0 Headers (Support 2 USB 2.0 ports) (Supports ESD Protection)
  • Volume (liters)
    - 8L
  • Power Unit
    - 500W power supply (80+ Bronze, peak 550W)
  • Accessory
    - Quick Installation Guide
    - 2 x SATA Data Cables
    - 1 x Screws Package
  • Dimension
    - 168 (W) x 219.3 (D) x 218.3(H) mm (excl. Protrusions)
    - 168 (W) x 236.1 (D) x 221.6(H) mm (incl. Protrusions)
  • OS
    - Microsoft® Windows® 10 64-bit / 11 64-bit
