Mechanical
Dimensions 289 x 280 x 52 mm (11.38 x 11.02 x 2.05")
Weight 1.4 kg (3.1 lb)
Enclosure materials Polycarbonate, acrylonitrile butadiene styrene
Hardware
Networking interface (1) 10/100 MbE RJ45 LAN port
Management interface Ethernet In-band
Bluetooth
Power TransPort output 27V DC, 100W (with 1 power adapter)
27V DC, 200W (with 2 power adapters)
Power method (2) 27V DC, 4.4A power adapters (120W Power TransPort Adapter not included)
Backup power (1) 25.2V DC, 7.93A rechargeable Li-ion battery pack (included)
(1) 24V DC, 8.33A lead acid battery input* (battery not included)
*Connect to a lead-acid battery only. Using another battery type could be hazardous.
Max. power consumption 3W (excludes Power TransPort output and battery charger)
ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV
Ambient operating temperature -5 to 40° C (23 to 104° F)
Ambient operating humidity 5 to 95% non-condensing
Certifications CE, FCC, IC
LEDs
System Status
RJ45 data port Link/activity
Power TransPort On/Off
Compatibility
Supported models UISP Console
UISP Router (installed with UISP Box)
UISP Router Pro
UISP Switch (installed with UISP Box)
UISP Switch Pro
Software
Management application UISP: Version 1.4.5 and later
