| Expansion Slots |
| |
| PCI-E |
- 1 PCI-E 4.0 x16 Left Riser Slot,
- 1 PCI-E 3.0 x4 (in x8 slot)
|
| M.2 |
- M.2 Interface: 1 PCI-E 4.0 x4; 1 PCI-E 3.0 x4
- Form Factor: 2280/22110
- Key: M-Key
- Double Height Connector
|
| |
| |
| System BIOS |
| |
| BIOS Type |
|
| BIOS Features |
- ACPI 6.0
- SMBIOS 3.3
- Plug and Play (PnP)
- RTC (Real Time Clock) Wakeup
- UEFI 2.7
- USB Keyboard support
- PCI 3.0
|
| |
| |
| Management |
| |
| Software |
|
| System Management Software |
- IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
|
| Power Configurations |
|
| |
| |
| PC Health Monitoring |
| |
| Voltage |
- VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset Voltage, Chassis intrusion header, 6 -fan status, +5V standby, +5V, +3.3V, +12V, Memory Voltages
|
| LED |
- UID/Remote UID
- CPU / System Overheat LED
|
| Temperature |
- Monitoring for CPU and chassis environment
- CPU thermal trip support
- Thermal Monitor 2 (TM2) support
- PECI
|
| FAN |
- 6x 4-pin fan headers (up to 6 fans)
- Thermal control tachometer fan connectors
- Fan speed control
- 6 fans with tachometer status monitoring
- Overheat LED indication
|
| Other Features |
- WOL
- UID
- Node Manager Support
- M.2 NGFF connector
- CPU thermal trip support for processor protection
- Control of power-on for recovery from AC power loss
- Chassis intrusion header
- Chassis intrusion detection
- ACPI power management
|
| |
| |
| Operating Environment |
| |
| Operating Temperature Range |
- 0°C - 50°C (32°F - 122°F)
|
| Non-Operating Temperature Range |
- -40°C - 70°C (-40°F - 158°F)
|
| Operating Relative Humidity Range |
- 8% - 90% (non-condensing)
|
| Non Operating Relative Humidity Range |
- 5% - 95% (non-condensing)
|
|
