Supermicro INTEL Xeon (8-core) E5-2620V4 2,1GHZ 20MB LGA2011-3 tray

Essentials Product Collection Intel® Xeon® Processor E5 v4 Family Code Name Products formerly Broadwell Vertical Segment Server Processor Number E5-2620V4 Status Launched Launch Date Q1'16 Lithography 14 nm Use Conditions Server/Enterprise CPU Specifications # of Cores 8 # of Threads 16 Processor Base Frequency 2.10 GHz Max Turbo Frequency 3.00 GHz Cache 20 MB Intel® Smart Cache Bus Speed 8 GT/s # of QPI Links 2 Intel® Turbo Boost Technology 2.0 Frequency‡ 3.00 GHz TDP 85 W VID Voltage Range 0 Supplemental Information Embedded Options Available Yes Datasheet View now Memory Specifications Max Memory Size (dependent on memory type) 1.5 TB Memory Types DDR4 1600/1866/2133 Max # of Memory Channels 4 Max Memory Bandwidth 68.3 GB/s Physical Address Extensions 46-bit ECC Memory Supported ‡ Yes Expansion Options Scalability 2S PCI Express Revision 3.0 PCI Express Configurations ‡ x4, x8, x16 Max # of PCI Express Lanes 40 Package Specifications Sockets Supported FCLGA2011-3 Max CPU Configuration 2 TCASE 74°C Package Size 45mm x 52.5mm Advanced Technologies Intel® Turbo Boost Technology ‡ 2.0 Intel vPro® Platform Eligibility ‡ Yes Intel® Hyper-Threading Technology ‡ Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes Intel® Transactional Synchronization Extensions Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Intel® Demand Based Switching Yes Thermal Monitoring Technologies Yes Intel® Flex Memory Access No Intel® Identity Protection Technology ‡ No Security & Reliability Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Intel® Trusted Execution Technology ‡ Yes Execute Disable Bit ‡ Yes
