Processor / System Bus
2 x Socket P+ (LGA 4189)
3rd Gen Intel® Xeon® Scalable Processors Family(270w)
*Refer to support page for more information
UPI (11.2 GT/s)
Generation
E10
Core Logic
Intel® C621A Chipset
Memory
Total Slots :
32 (8-channel per CPU, 16 DIMM per CPU)
Capacity :
Maximum up to 6TB per socket
Memory Type :
DDR4 3200/2933 RDIMM
DDR4 3200/2933 LRDIMM
DDR4 3200/2933 LR-DIMM 3DS
3200/2933
Memory Size :
64GB, 32GB, 16GB, 8GB RDIMM
256GB, 128GB, 64GB RDIMM 3DS
128GB RDIMM 3DS/LR-DIMM 3DS
512GB, 256GB, 128GBIntel® Optane™ DC Persistent Memory
* Refer to support page for more information
* Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.
Expansion Slots
Up to 9 x Expansion slots
2 x PCIe Gen4 x8 or 1 x PCIe Gen4 x16, FHFL (CPU1 x1)
1 x PCIe Gen4 x8, FHFL (CPU1 x1)
1 x PCIe Gen4 x16, FHFL or OCP 3.0 NIC socket (CPU1 x1)
4 x PCIe Gen4 x8 or 2 x PCIe Gen4 x16, FHFL (CPU2 x2)
1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2 x1)
*Installing GPU cards will occupied expansion slots.
Storage
Storage Controller :
Intel C621A
Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)
(Support Software RAID 0, 1, 5, 10 )
Intel®VROC (For Linux/Windows)
(Support Software RAID 0/1/5/10 )
SAS Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional)
Broadcom MegaRAID 9560-16i (Optional)
Drive Bays
Front bays:
24 x 2.5" hot-swap bays (12x NVMe + 12x SATA/SAS* or 12x NVMe + 12x NVMe/SATA/SAS*)
2 x M.2 connector (NGFF 2280/2260. PCIe Gen4x4 link)
*SAS support only from SAS HBA/RAID card
**Support tri-mode card
System Fan
4
Networking
Option 1
1 x Quad Port Intel I350-AM4 1G LAN Controller + 1 x Mgmt LAN
or
Option 2
1 x Dual Port Intel X710-AT2 Gigabit 10G LAN Controller + 1 x Mgmt LAN
or
None x + 1 x Mgmt LAN
Graphic
Aspeed AST2600 with 64MB VRAM
Multi-GPU Support
Please find the latest GPU support from https://servers.asus.com/support/gpu
Front I/O Ports
2 x USB 3.2 Gen1 ports
Rear I/O Ports
2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Mgmt LAN port
4/2 x NIC ports*
* The number of NIC ports available depends on the LAN Controller card installed.
Switch/LED
Front Switch/LED:
1 x Power switch/LED
1 x Location switch/LED
1 x Reset switch
1 x HDD Access LED
1 x Message LED
LAN 1-4 LED
* LAN3-4 for Mezzazine card use
Rear Switch/LED:
1 x Power switch
1 x Q-Code/Port 80 LED
1 x Location LED
OS Support
Please find the latest OS support from https://servers.asus.com/support/os
Management Solution
ASUS Control Center(Classic) On-Board ASMB10-iKVM for KVM-over-IP
Regulatory Compliance
BSMI, CE, FCC(Class A)
Dimensions
840mm x 449mm x 88mm(2U) 33.07" x 17.68" x 3.46"
Form Factor
2U
Weight
Net Weight :21.69KG
Power Supply
1+1 Redundant 2400W 80 PLUS Titanium Power Supply
Rating: 100-127Vac/ 200-240Vac, 13.8A/15A (for each inlet), 50/60Hz, Class I
1+1 Redundant 1600W 80 PLUS Platinum Power Supply
Rating: 100-127Vac/200-240Vac, 13A/9.5A (for each inlet), 50-60Hz, Class I
Environment
Operation temperature: 10? ~ 35? Non operation temperature: -40? ~ 60? Non operation humidity: 20% ~ 90% ( Non condensing)
Note
*If only 1 CPU is installed, some functions might be not available.
*SAS support only from SAS HBA/RAID Card
*If PCIe expansion slot 3 choosing OCP3.0 option, slot 4 will be limited to support PIKE card only
CPU Heatsink/ Cooler
2
Fan
1 (For supporting GPU SKU, it will have external fan)
