ASUS RS700A-E9-RS12 WOD 2CEE EN WOC WOM WOS WOR IK9(w o DVD, 4NVME supprted, 800W Platinum*2)AMD Epyc 2 Socket, 32DIMMI

Processor / System Bus 2 x Socket P (LGA 3647) 1st and 2nd Gen Xeon® Scalable Processor Family *Refer to support page for more information UPI (10.4 GT/s) Generation E9 Core Logic Intel® C621 Chipset Memory Total Slots : 24 (6-channel per CPU, 12 DIMM per CPU) Capacity : Maximum up to 3072GB LR-DIMM 3DS Memory Type : DDR4 2933/2666/2400 RDIMM DDR4 2933/2666/2400 LRDIMM DDR4 2933/2666/2400 LR-DIMM 3DS DDR4 Intel® Optane™ DC Persistent Memory Memory Size : 32GB, 16GB, 8GB, 4GB RDIMM 64GB, 32GB LRDIMM 128GB, 64GB LR-DIMM 3DS 512GB, 256GB, 128GBIntel® Optane™ DC Persistent Memory * Refer to support page for more information * Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU. Expansion Slots 1 x PCI-E x16 (Gen3 x16 link), FH, HL 1 x PCI-E x16 (Gen3 x8 link), LP, HL 1 x PCI-E x8 (Gen3 x8 link), LP, HL 1 x OCP 2.0 Mezzanine (Gen3 x16 link) Storage SATA Controller : Intel® Lewisburg PCH 10 x SATA3 6Gb/s ports + 1 x M.2 connector or 9 x SATA 6Gb/s ports + 2 x M.2 connector Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows) (Support Software RAID 0, 1, 5, 10 ) Intel®VROC (For Linux/Windows) (Support Software RAID 0/1/5/10 ) Optional kits Controller : ASUS PIKE II 3008 8-port SAS HBA card ASUS PIKE II 3108 8-port SAS HW RAID card 12G SAS Support HDD Bays 12 x 2.5" Hot-swap Storage Bays (Hybrid storage with up to 8 x NVMe, 8 x SAS and 10 x SATA) 2 x M.2 (22110, 2280, 2260, 2242) (Support SATA/PCIe M.2,SATA RAID) *SAS support via PIKE Networking 1 x Dual Port Intel I350-BT2 Gigabit LAN controller + 1 x Mgmt LAN Graphic Aspeed AST2500 with 64MB VRAM Rear I/O Ports 2 x USB 3.0 ports 1 x VGA port 2 x RJ-45 GbE LAN ports 1 x RJ-45 Mgmt LAN port Switch/LED Rear Switch/LED: 1 x Power switch 1 x Q-Code/Port 80 LED 1 x Message LED 1 x Drive LED 1 x Location LED Front Switch/LED: 1 x Power switch/LED 1 x Location LED 1 x Message LED 1 x DriveD LED LAN 1-2 LED OS Support Please find the latest OS support from http://www.asus.com/ Management Solution ASUS Control Center(Classic) On-Board ASMB9-iKVM for KVM-over-IP Dimensions 686mm x 444mm x 44mm(1U) 27" x 17.48" x 1.73" Form Factor 1U Weight Net Weight : 16.8KG Gross Weight : 18.35KG Power Supply 1+1 Redundant 800W 80 PLUS Platinum Power Supply Rating: 100-127/200-240Vac, 9.4A/4.72A, 47-63Hz Class I or 240Vdc, 4.6A (240Vdc Only for China) Environment Operation temperature: 10? ~ 35? Non operation temperature: -40? ~ 60? Non operation humidity: 20% ~ 90% ( Non condensing)
