| Expansion Slots |
| PCIe |
- 1 PCIe 5.0 x16 Right Riser Slot,
- 1 PCIe 5.0 x16 Left Riser Slot,
- 2 PCIe 5.0 x16 AIOM Networking Slot
|
| M.2 |
- M.2 Interface: 2 PCIe 3.0 x2
- Form Factor: 2280/22110
- Key: M-Key
|
| System BIOS |
| BIOS Type |
- AMI 32MB SPI Flash EEPROM
|
| BIOS Features |
- ACPI 6.4
- SMBIOS 3.5 or later
- UEFI 2.8
- Plug and Play (PnP)
- USB Keyboard support
|
| Management |
| Software |
- SuperCloud Composer®, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software, IPMI Utilities
|
| Power Configurations |
- ACPI Power Management, Power-on mode control for AC power loss recovery
|
| Security |
| Hardware |
- Trusted Platform Module (TPM) 2.0
|
| PC Health Monitoring |
| Voltage |
- VBAT, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, VRM temperature, CPU thermal trip support, 1.8V standby
|
| LED |
- UID/Remote UID
- BMC/IPMI Heartbeat LED
|
| Other Features |
|
| FAN |
- 6x 4-pin fan headers (up to 6 fans)
|
| Operating Environment |
| Operating Temperature Range |
- 10°C - 35°C (50°F - 95°F)
|
| Non-Operating Temperature Range |
- -40°C - 70°C (-40°F - 158°F)
|
| Operating Relative Humidity Range |
- 8% - 90% (non-condensing)
|
| Non Operating Relative Humidity Range |
- 5% - 95% (non-condensing)
|
|
