Overview
Dimensions
471.1 x 257.5 x 94.3 mm
(18.6 x 10.1 x 3.7")
WiFi Standard
WiFi 5
Spatial Streams
12
Coverage Area
465 m2 (5,000 ft2)
Max. Client Count
1500+
Uplink
10 GbE
Mounting
Wall, Pole (Mounts Included), VESA (Optional)
Weatherproofing
IP67
Power Method
PoE++
Performance
MIMO
5 GHz
Low/Mid/High-band: 4 x 4 (DL MU-MIMO)
Max. Data Rate
5 GHz
Low/Mid/High-band: 1.7 Gbps (BW80)
Antenna Gain
5 GHz
Small cell: 15 dBi
Large cell: 10 dBi
Max. TX Power
5 GHz
25 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
802.11n
6.5 Mbps to 600 Mbps (MCS0 - MCS23, HT 20/40)
Features
Wireless Meshing
Yes
Band Steering
Yes
802.11v BSS Transition Management
Yes
802.11r Fast Roaming
Yes
802.11k Radio Resource Management (RRM)
Yes
Advanced Radio Management
Yes
Passpoint (Hotspot 2.0)
Yes
Captive Hotspot Portal
Custom Branding Landing Page
Yes
Voucher Authentication
Yes
Payment-Based Authentication
Yes
External Portal Server Support
Yes
Password Authentication
Yes
Guest Network Isolation
Yes
Client Device Isolation
Yes
WiFi Schedules
Yes
RADIUS over TLS (RadSec)
Yes
Dynamic RADIUS-assigned VLAN
Yes
Hardware
Max. Power Consumption
31W
Includes PoE Adapter
Yes
Supported Voltage Range
44—57V DC
Networking Interface
(1) GbE RJ45 port
(1) 1/10 GbE ICM Ethernet port
Weight
3.2 kg (7.1 lb)
Pole Mount Diameter
1~3" (25~76 mm)
Antennas
(1) Integrated dual-mode antenna array
Management
Ethernet
Bluetooth
Enclosure Material
Polycarbonate, aluminum alloy
LEDs
System
R/G/B
Channel Bandwidth
HT 20/40, VHT 20/40/80, HE 20/40/80 (MHz)
Certifications
CE, FCC, IC
Operating Frequency
US/CA:
U-NII-1: 5150 - 5250 MHz
U-NII-2A: 5250 - 5350 MHz
U-NII-2C: 5470 - 5670 MHz
U-NII-3: 5725 - 5850 MHz
Worldwide:
5150 - 5250 MHz
5250 - 5350 MHz
5470 - 5670 MHz
Ambient Operating Temperature
-40 to 70° C (-40 to 158° F)
Ambient Operating Humidity
5 to 95% noncondensing
